P3.91 indoor large theater led display screen wall

FOB Reference Price:Get Latest Price
US $1,250-1,350 / Square Meter | 6 Square Meter/Square Meters (Min. Order)
Supply Ability:
1000 Square Meter/Square Meters per Month
Port:
Shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Eachinled
Model Number:
P3.91 SMD2121
Usage:
Indoor
Tube Chip Color:
Full Color
Display Function:
Video
Pixels:
3.91mm
Screen Dimension:
4m*3m
LED chip brand:
Epistar
Power Supply:
Meanwell
IC:
MBI5024
Driving Method:
1/16 scan
Luminance of white balance:
Above 1500nits
Viewing angle:
140H,120V
Packaging & Delivery
Packaging Details
Flight case:530mmx650mmx1000mm,6panels in one.
Delivery Time
25 days after deposit received

P3.91 indoor large theater led display screen wall

Product Features:

1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.





Technical Specification:

Indoor Die casting Aluminum 500mm Rental LED Displays

Module

Pitch/mm

P3.91

P4.8

P5.2

P6.25

Module size/mm

250x250

250x250

250x250

250x250

Density of pixel/(dots/m2)

65536

43264

43402

40,000

Pixel composition

1R1G1B

1R1G1B

1R1G1B

1R1G1B

Led encapsulation

SMD2121

SMD2121

SMD3528

SMD3528

Resolution of module

64X64

52x52

48x48

40x40

Main

Optimum viewing distance

3-10m

4-15m

5-18m

6-20m

View angle / °

140H,120V

140H,120V

140H,120V

140H,120V

Max power consumption/W/M2

1,100

1,100

1,000

1,000

Size of cabinet/mm

500X500

500x500

500x500

500x500

Resolution of cabinet

128X128

104x104

96x96

80x80

Weight of cabinet/kg

9

9

9

9

Driving method

1/16 scan constant current

1/13 scan constant current

1/12 scan constant current

1/4scan constant current

Refresh rate Hz/S

1500

1500

1500

1500

Luminance of white balance

≥1500 nits

≥1500 nits

≥2000 nits

≥2000 nits

Operation of Environmental Temperature/°C

below 30  to  above 50

Working vlotage

110-220 VAC/+/- 10%

Grey scale/color

displaying colors16.7M(synchronized)

Brightness adjustment

256 levels of each color(manually),100 levels of each color(automatically)

Input signal

RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc

Control system

linsn(sending card,receiving cards and Hubs)

Average of non-failure life

>50,00h

Life span

>100,000h

Defect dot rate

<0.0001



Gallery:
